Product Details
＋
Features
- Modular mount for 1 to unlimited wall display configurations
- Push-To-Open function for mounting flat screens into a recessed wall
- Reduce service time with Push-To-Open function
- Landscape or Portrait screen installation
- Compatible with VESA standard (Max. 400 x 400 mm)
- Additional VWM-01 mounting arms and extension bars available for fast and easy modular installation
- Weight capacity: 80 kg
Specification
Mounting
- Display
- 43"-86" Displays
- Mounting Pattern
- Max. 800 x 400 mm
Loading
- Weight Capacity
- 80.0 kg (176.4 lb)
Screw Adjustment
- Up
- 3.3 mm
- Down
- 3.3 mm
- Right
- 24.5 mm
- Left
- 24.5 mm
Exterior
- Material
- Steel and Aluminium
- Colour
- Black and Silver
Dimensions
- Product (W x H x D)
- Packaging (W x H x D) (1set)
- 560.0 x 90.0 x 250.0 mm (22.0" x 3.5" x 9.8")
Weight
- Net Weight
- 7.3 kg (16.1 lb)
- Gross weight (1set)
- 8.0 kg (17.6 lb)
Packaging
- 1 Carton
- 1 pc
- 1 Pallet
- 40 pcs
